Gallina ARCOPLUS 626 Satin Opal Smooth 6500 x 600 x 38mm

ArcoPlus®626 is a modular system of co-extruded 6 walls polycarbonate panels with 600mm module, assembled using a click-on system to aluminium profiles. Used for vertical glazing, flat roofing (min. slope 5%) and curved roofing (minimum radius 4m).

article nr : 438723
read more

descriptions

ArcoPlus®626 is a modular system of co-extruded 6 walls polycarbonate panels with 600mm module, assembled using a click-on system to aluminium profiles. Used for vertical glazing, flat roofing (min. slope 5%) and curved roofing (minimum radius 4m).

Technical Description

Brief technical information - ArcoPlus® 626

  • Thickness: 20 mm
  • Structure: 6 walls
  • Module width: 600 mm
  • Thermal insulation: 1.7 W/m²K
  • Acoustic insulation: 20 dB
  • Fire class: EuroClass B-s1,d0

specifications

Vendor Colorname
Satin Opal
Color or RAL
Opal
Length mm
6500 mm
Width mm
600 mm
Thickness mm
38 mm
Material
PC
Delivery Form
Sheet
Surface Structure Recto
Smooth
Surface Structure Verso
Smooth
Vink Eco Shift
Applicable
Outside Use
yes
% Light Transmission
33 %
UV Resistance
2-sides UV-resistant
Fire Behaviour
fire retardant
Fire Classification
EN13501-1: B s1 d0
Production Technique Pipes
Extruded
